| Specifications：(Meets F.C.C.Class A & CE & RoHS) | |
| Power Supply | Single ATX/PS2 Power Max 860 (Depth: 185mm) (Optional) Mini Redundant Power Max 600 Watts (Depth: 185mm) (Optional) |
| Motherboard | Max to 12" (W) x 10.6" (D) Compliant ATX/SSI CEB 1.1 |
| Fans | Front : 2 x Axial (120 x 120 x 25mm) Middle : none Rear : 1 x Axial (120 x 120 x 25mm) |
| Indicatiors LEDs | 1 x Disk status LED 1 x Power LED 2 x NIC LEDs 1 x Fan Fault LED |
| Switches | Power Button ON/OFF Reset Button ON/OFF |
| Drive Bays | 4 x 5.25" CD-ROM 8 x 3.5" Hard Disks (internal) |
| Front USB port | 2 USB Ports with Cable (option) |
| Expansion Slot | PCI & PCI Express Card (Max 220mm Depth) |
| Air-Filter | Chemical filter washable |
| Material | SECCESAXZ Standard (ROHS) |
| Finished | Black(RAL 9011) Beige(RAL 7035) |
| Temperature | 0°C(32F) ~ 50° C(122F) (Non-operation) |
| Humidity | 5%~95% Non-Condensing |
| Dimension | MM:
(W)424 x (H)177 x (L)508 INCH: (W)19" x (H)6.97" x (D)20" |
| Shipping Dimension | MM:
(W)546 x (H)307 x (L)644 INCH: (W)21.5" x (H)12.09" x (D)25.35" |
| Product Applications | Web Server Proxy Server VPN Gateway High-End Workstation Print Server |
